SBM-200 H Automatic Swing Arm Bandsaw Machine

Name: SBM-200 H Automatic Swing Arm Bandsaw Machine
Brand: MULTICUT MACHINE TOOLS
Price: 500000 INR
Availability: InStock

Price 500000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

SBM-200 H Automatic Swing Arm Bandsaw Machine Specification

General Use
Metal Cutting

Weight (kg)
450 Kilograms (kg)

Computerized
No

Automatic
Yes

Control System
Manual

Cutting Speed
24 - 76 m/m

Cutting Function
Full Automatic

BladeSize
3505 x 27 x 0.9 mm

Drive Type
Electric

Dimension (L*W*H)
1550 x 575 x 875 Millimeter (mm)

Feature
Good Quality, High Efficiency

Color
Green

Warranty
1 Year

SBM-200 H Automatic Swing Arm Bandsaw Machine Trade Information

Minimum Order Quantity
1 Piece

FOB Port
EX WORKS

Payment Terms
Cash in Advance (CID), Cheque

Supply Ability
1 Piece Per Month

Delivery Time
60 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
PLASTIC WRAPPING, WOODEN pallet packing for export

Main Export Market(s)
Asia, Australia, Central America, North America, South America, Eastern Europe, Western Europe, Middle East, Africa

Main Domestic Market
, All India, South India, Central India, West India, North India, East India, Gujarat, Karnataka, Kerala, Lakshadweep, Mizoram, Meghalaya, Manipur, Andhra Pradesh, Bihar, Chandigarh, Daman and Diu, Goa, Jharkhand, Odisha, Punjab, Assam, Delhi, Dadra and Nagar Haveli, Andaman and Nicobar Islands, Arunachal Pradesh, Chhattisgarh, Haryana, Himachal Pradesh, Jammu and Kashmir, Madhya Pradesh, Maharashtra, Nagaland, Rajasthan, Sikkim, Tamil Nadu, Telangana, Tripura, Pondicherry, Uttar Pradesh, Uttarakhand, West Bengal

Certifications
ISO 9001:2015, IEC: 3407003757, MSME REGISTERED COMPANY (GJ-24-0020495)

About SBM-200 H Automatic Swing Arm Bandsaw Machine

Automatic Swing Arm Band Saw Machine is based on advanced hydraulic technology and feature automatic swing arm type configuration so as to provide for convenient operation handling. Some of its features include economical efficient cutting operations; suitable for use on channels, tubes, angles; flexible rotation of swing arm. Further, the self-lubricating system support provided in the system also allows for reduced wear as well as extended service life. This machine is very efficient.

Automatic Swing Arm Band Saw Machine Specification

SR.NO	PRODUCT TECHNICAL SPECIFICATIONS	MODEL
		SBM 200 H
1	CUTTING CAPACITY ROUND BAR IN MM	200
2	CUTTING CAPACITY SQUARE BAR IN MM	200 X 150
3	MAIN DRIVE MOTOR HP 1440 RPM	1.5 HP
4	HYDRAULIC MOTOR HP 1440 RPM	0.5 HP
5	COOLANT MOTOR HP- 1440 RPM	0.13 HP
6	Total Power H.P.	2.13 HP
7	BLADE SIZE IN MM	3505 X 27X 0.09
8	Band Tension	MANUAL
9	Saw Feed Control	HYDRAULIC
10	JOB CLAMPLING	HYDRAULIC
11	Hydraulic Tank Capacity (Litre)	25
12	COOLANT TANK CAPACITY (LITRE)	25
13	CUTTING SPEED MTR/MIN	17-26-38-68
14	FLOOR SPACE L X W X H	1550 x 575 x 875
15	NET WEIGHT IN KG	850
16	Cutting Taper Accuracy, for En-8mm /100mm	0.2 MM
