LMG 650 A-NC Fully Automatic Horizontal Double Column Band Saw L M Guide Type Machine

Name: LMG 650 A-NC Fully Automatic Horizontal Double Column Band Saw L M Guide Type Machine
Brand: MULTICUT MACHINE TOOLS
Price: 1750000 INR
Availability: InStock

Price 1750000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

LMG 650 A-NC Fully Automatic Horizontal Double Column Band Saw L M Guide Type Machine Specification

Material
Others

Cutting Capacity
650 mm

Features
Superior Stability, Accuracy and Efficiency

Operate Method
Electric

Usage
Industrial

Cutting Speed
15 Mtr / Min m/m

Size
4300 X 2900 X 2900 mm

Product Type
LMG 650 A-NC Fully Automatic Horizontal Double Column Band Saw L M Guide Type Machine

Weight
8600 Kg Kilograms (kg)

Color
Yellow

LMG 650 A-NC Fully Automatic Horizontal Double Column Band Saw L M Guide Type Machine Trade Information

Minimum Order Quantity
1 Unit

FOB Port
EX WORKS

Payment Terms
Cash in Advance (CID), Cheque

Delivery Time
15-20 Days

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
PLASTIC WRAPPING, WOODEN pallet packing for export

Main Export Market(s)
Australia, Eastern Europe, South America, Central America, Africa, Middle East, Western Europe, Asia, North America

Main Domestic Market
Dadra and Nagar Haveli, Delhi, Rajasthan, Jammu and Kashmir, West India, Madhya Pradesh, Chandigarh, Assam, Arunachal Pradesh, Chhattisgarh, Punjab, Tripura, South India, Meghalaya, Nagaland, Tamil Nadu, Bihar, Jharkhand, Gujarat, Sikkim, Haryana, Daman and Diu, Uttarakhand, Himachal Pradesh, Maharashtra, All India, Central India, Mizoram, East India, Lakshadweep, Goa, Manipur, Uttar Pradesh, Karnataka, Andhra Pradesh, Odisha, Kerala, Pondicherry, West Bengal, Telangana, North India, Andaman and Nicobar Islands

Certifications
ISO 9001:2015, IEC: 3407003757, MSME REGISTERED COMPANY (GJ-24-0020495)

About LMG 650 A-NC Fully Automatic Horizontal Double Column Band Saw L M Guide Type Machine

The LMG 650 A-NC Fully Automatic Horizontal Double Column Band Saw L M Guide Type Machine is an industrial-grade sawing machine designed to provide maximum efficiency and accuracy in cutting operations. It is capable of cutting a wide range of materials, such as mild steel, at a maximum speed of 15 m/min with a cutting capacity of 650 mm. The machine is equipped with a double column saw frame for increased stability and accuracy, and a guide type system for precise cutting. The machine is powered by a heavy-duty motor and is designed to run continuously for long periods of time. It also features a yellow color for easy identification and an impressive weight of 8600 kg. The LMG 650 A-NC Fully Automatic Horizontal Double Column Band Saw L M Guide Type Machine is ideal for industrial applications and is manufactured by a reliable exporter, manufacturer, and supplier. It is designed to provide maximum efficiency and accuracy in cutting operations and is the perfect choice for any industrial setting.

SR.NO	PRODUCT TECHNICAL SPECIFICATIONS	MODEL
		LMG 650 A
1	CUTTING CAPACITY ROUND DIA.MM	650 MM
2	CUTTING CAPACITY RECTANGLE.MM	650 X 650 MM
3	MAIN DRIVE MOTOR HP	12.5. HP
4	HYDRAULIC MOTOR HP	2 HP
5	COOLANT MOTOR HP	0.24 Hp
6	Chip Brush Gear Motor (H.P.)	0.25 HP
7	TOTAL POWER HP	15 HP
8	CUTTING SPEED(MTR/MIN)	15-65
9	BLADE SIZE IN MM	6900541.6
10	FLOOR SPACE FOR AUTO MACHINE -LXWXH MM	4300X2900X2900
11	SINGLE INDEXING STROCK(MM FOR AUTOMATIC	0 TO 350 MM
12	MULTIPLE INDEXING STROCK(MM FOR AUTOMATIC	9 TIMES
13	BAND TENSION	HYDRAULIC
14	SAW FEED CONTROL	HYDRAULIC
15	HYDRAULIC TANK CAPACITY (LITRE)	60 LTRS
16	COOLANT TANK CAPACITY (LITRE)	60 LTRS
17	NET WEIGHT AUTOMATIC M/C (APPROX) KG	8600 KG
18	CUTTING TAPER ACCURACY FOR EN-8D FOR 100MM DIA	0.3 MM
19	CUTTING LENGTH ACCURACY MM/INDEX PER STOCK	0.2 MM

FAQs of LMG 650 A-NC Fully Automatic Horizontal Double Column Band Saw L M Guide Type Machine:

Q: What materials can the LMG 650 A-NC Fully Automatic Horizontal Double Column Band Saw L M Guide Type Machine cut?

A: The LMG 650 A-NC Fully Automatic Horizontal Double Column Band Saw L M Guide Type Machine is capable of cutting a wide range of materials, such as mild steel.
