Home » Products » Swing Type Complete Hydraulic Band Saw Machine

Swing Type Complete Hydraulic Band Saw Machine

The offered ranged of Swing Type Band Saw Machine is Completely Hydraulic Based, which includes rigid pedestal bearings to support the vertical saw head. It also comprises of wear parts that are built using tungsten carbide and roller used to guide the blade so that accurate and smooth finished cuts are rendered. In the mentioned machines, a hydraulic cylinder is used for controlling the motion of the head in the upward and downward direction, whereas its feed is controlled by the pressure relied valve. The entire process used in this array is done using the hydraulic vice and is known to be clamping. In our provided Hydraulic Band Saw Machines, the blade is always kept in perpendicular to the jaw.

Key Points:

  • Less consumption of power because of continuous and quick cutting
  • Cost for tooling and equipment is reduced because of quality blades
  • Roller bearings are provided with the carbide guide
  • The blade is aligned in the vertical direction
Swing Type Band Saw Machine
close
Swing Type Band Saw Machine
SBM-200 H

Swing Type Band Saw Machine

We manufacture, supplier and exporter of Swing Type Complete Swing Type Complete Hydraulic Band Saw Machine (SBM-200H) as per the specifications of our customers. Used for cutting different types of cutting materials, our machines are reckoned for trouble-free performance, high cutting capacity and longer services life. Clients are provided by us precision engineered Swing Type Complete Hydraulic Band Saw Machine with various specifications at most economical  prices.Swing Type Band Saw Machine offered comes based on advanced hydraulic technology and feature automatic swing arm type configuration so as to provide for convenient operation handling. The whole system is so designed to provide for versatile cutting operations at 90° and angular cutting ratio of 0° to 60°. Some of its features include economical & efficient cutting operations; suitable for use on channels, tubes, angles; flexible rotation of swing arm; guarantee flexible rotation and good reliability; provides for reduced wear and extended service life.

Special Features:

  • Adjustable Hydraulic cutting feed
  • Blade alignment in vertical & horizontal side
  • Carbide guide with roller bearings
  • Higher hydraulic cutting speed
  • Less power consumption due to continuous cutting
  • Less tooling cost due to higher blade life
  • Good parallelism in cutting
  • Heavy duty hydraulic clamping vice for job
  • Heavy duty worm/helical reduction gear box
  • Optional swivel vice for angle cutting
  • Complete electrical system
  • Complete hydraulic system
  • Complete coolant system
  • Machine instruction manual
  • Chip brush for scrap removing

Technical Specifications

Technical Data

SBM - 200 H

Cutting Capacity


Round Bar In Mm

200

Square Bar In Mm

200 x 150

Main Drive Hp 1440 Rpm

1.5 HP

Hydraulic Motor H.P 1440 Rpm

0.5 HP

Coolant Motor Hp 1440 Rpm

0 14 HP

Blade Size In Mm

3505 x 27 x 0.9

Cutting Speed (Mtr / Min)

24 - 76

Coolant Tank In Litre

40

Floor Space l x W x N

1550 x 575 x 675

Net Weight In Kg

410


Swing Type Semi Automatic Bandsaw Machine
close
Swing Type Semi Automatic Bandsaw Machine
SBM-400 H

Swing Type Semi Automatic Bandsaw Machine

We are widely appreciated for offering a premium collection of Swing Type Semi Automatic Bandsaw Machine at marginal prices. By utilizing superior grade components and innovative techniques, this machine is manufactured under the supervision of our dexterous professionals. For precise cutting of metal, plastic and wood, the offered Swing Type Semi Automatic Bandsaw Machine is widely used in heavy duty applications.

Technical Details:

Technical Data

SBM - 400 H

Cutting Capacity


Round Bar In Mm

400

Square Bar In Mm

400 x 350

Main Drive Hp 1440 Rpm

3 HP

Hydraulic Motor H.P 1440 Rpm

1 HP

Coolant Motor Hp 1440 Rpm

0 14 HP

Blade Size In Mm

4100 x 34 x 1.1

Cutting Speed (Mtr / Min)

24 - 76

Coolant Tank In Litre

75

Floor Space l x W x N

2750 x 850 x 1200

Net Weight In Kg

1250




Swing Type Hydraulic Band Saw Machine
close
Swing Type Hydraulic Band Saw Machine
SBM-300 H

Swing Type Hydraulic Band Saw Machine

The provided Swing Type Hydraulic Band Saw Machine is extensively used for the cutting of metal, wood and various other materials in different shapes and sizes. This machine is manufactured using the best quality components and ultramodern techniques with the help of our ingenious professionals. This Swing Type Hydraulic Band Saw Machine is extensively demanded in the market due to its flawless design, long life and excellent performance.

Technical Details:

Technical Data SBM - 300 H
Cutting Capacity
Round Bar In Mm 300
Square Bar In Mm 303 x 250
Main Drive Hp 1440 Rpm 2 HP
Hydraulic Motor H.P 1440 Rpm 0.5 HP
Coolant Motor Hp 1440 Rpm 0 14 HP
Blade Size In Mm 3760 x 27 x 0.9
Cutting Speed (Mtr / Min) 24 - 76
Coolant Tank In Litre 60
Floor Space l x W x N 2450 x 850 x 1250
Net Weight In Kg 850






Major Export Countries are Russia , Middle East, United Kingdom, USA.
