Semi Automatic Double Column Band Saw Machine


Semi Automatic Bandsaw Machine
close
Semi Automatic Bandsaw Machine
LMG 200H

Semi Automatic Bandsaw Machine

With rich industry and market knowledge, we are successfully betrothed in providing the best quality Semi Automatic Bandsaw Machine. Our clients can purchase the offered machine from us at cost effective rates within committed time frame. It is manufactured by utilizing premium grade components and pioneering techniques by our knowledgeable professionals. In order to perform metal cutting operations with high accuracy, the offered Semi Automatic Bandsaw Machine finds its application in metalworking industry.

Special Features:

  • Hydraulic band tension
  • Auto saw frame height adjustment
  • Hydraulic full stroke clamping
  • Step less cutting feed regulation
  • Carbide & roller blade guide
  • Complete hydraulic system
  • Complete electrical system
  • Complete coolant system
  • Precise length setting
  • Hard chrome & ground solid guide rods
  • Imported self lubricating bearing bush
  • Fast approach of blade
  • Step pulley with 'v' belt
  • Split front vice machine
  • Bimetal band saw blade

Technical Details:

Technical Data BDC-1000 A
Cutting Capacity Round Dia. (mm) 1000
Cutting Capacity Rectangle (mm) 1000 x 1100
Main Drive H.P. (1440 Rpm.) 20
Hydraulic Motor H.P. (1440 Rpm.) 3
Coolant Motor H.P. (1440 Rpm.) 0.5
Chip Brush Gear Motor (H.P) 0.25
Cutting Speed (m / min) 15 - 80
Blade Size 10780 x 67 x 1.6
Floor Space Size L x W x H mm 6000x
3600x
3400
Single Indexing Stock (mm) 0 to 300
Multiple Indexing Stock (mm) 0
Band Tension Hydraulic
Saw Feed Control Hydraulic
Hydraulic Tank Capacity (Litre) 140
Coolant Tank Capacity (Litre) 90
Net Weight Automatic M/c. (approx.) Kg. 13500
Net Weight Semi - Automatic (approx.) Kg. 10500
Total Power H.P. 23.75
Cutting Taper Accuracy, for En-8mm /100mm ± 0.3
Cutting Length Accuracy mm / Index 0
Double Column Bandsaw Machine
close
Double Column Bandsaw Machine
BDC-800M

Double Column Bandsaw Machine

To meet the various metal cutting requirements of our prestigious clients, we are affianced in offering a broad assortment of Double Column Band Saw Machine. This machine is suitable for metal cutting purposes in different engineering and automotive industries. We offer this machine in different technical specifications so as to suit the requirements of the clients. The offered Double Column Band Saw Machine is tested on well-defined parameters in order to deliver flawless range at clients' end.

Specifications:

Technical Data BDC-800 M
Cutting Capacity Round Dia. (mm) 800
Cutting Capacity Rectangle (mm) 800 x 850
Main Drive H.P. (1440 Rpm.) 15
Hydraulic Motor H.P. (1440 Rpm.) 3
Coolant Motor H.P. (1440 Rpm.) 0.5
Chip Brush Gear Motor (H.P) 0.25
Cutting Speed (m / min) 15 - 80
Blade Size 8800 x67 x 1.6
Floor Space Size L x W x H mm 4800x 3100x 3000
Single Indexing Stock (mm) 0 to 300
Multiple Indexing Stock (mm) 0
Band Tension Hydraulic
Saw Feed Control Hydraulic
Hydraulic Tank Capacity (Litre) 120
Coolant Tank Capacity (Litre) 90
Net Weight Automatic M/c. (approx.) Kg. 10500
Net Weight Semi - Automatic (approx.) Kg. 7650
Total Power H.P. 18.75
Cutting Taper Accuracy, for En-8mm /100mm ± 0.3
Cutting Length Accuracy mm / Index 0
Semi Automatic Double Column Band Saw Machine
close
Semi Automatic Double Column Band Saw Machine
BDC - 420 M

Semi Automatic Double Column Band Saw Machine

Supported by a team of highly competent professionals, we are able to provide a top notch quality range of Semi Automatic Double Column Band Saw Machine. Customers admire the offered machine to be used for metal cutting applications due to its longer functional life and sturdiness. We offer this machine to the clients at market leading rates within promised time frame. Additionally, this Semi Automatic Double Column Band Saw Machine is manufactured with the use of quality assured components and contemporary techniques.

Specifications:

Technical Data BDC-420 M
Cutting Capacity Round Dia. (mm) 420
Cutting Capacity Rectangle (mm) 420 x 450
Main Drive H.P. (1440 Rpm.) 7.5
Hydraulic Motor H.P. (1440 Rpm.) 2
Coolant Motor H.P. (1440 Rpm.) 0.33
Chip Brush Gear Motor (H.P) 0.25
Cutting Speed (m / min) 15 - 90
Blade Size 6000 x 41 x 1.3
Floor Space Size L x W x H mm 3400x 2400x 2500
Single Indexing Stock (mm) 0 to 400
Multiple Indexing Stock (mm) 9 times
Band Tension Hydraulic
Saw Feed Control Hydraulic
Hydraulic Tank Capacity (Litre) 90
Coolant Tank Capacity (Litre) 60
Net Weight Automatic M/c. (approx.) Kg. 5100
Net Weight Semi - Automatic (approx.) Kg. 3350
Total Power H.P. 10.08
Cutting Taper Accuracy, for En-8mm /100mm ± 0.2
Cutting Length Accuracy mm / Index 0.2


Major Export Countries are Russia , Middle East, United Kingdom, USA.
